Control Panel Desk For Jetty Operator

Name: Control Panel Desk For Jetty Operator
Brand: EXPERT CONTROL & INFOTECH
Price: 200000.00 INR
Availability: InStock

Price 200000.00 INR/ Unit

Get a Price/Quote

Control Panel Desk For Jetty Operator Specification

Way
Single/Multiple Way

Current Rating
250 A

Protection Level
IP54

Operating Voltage
415 V

Features
Ergonomic design, robust construction, weatherproof, operator friendly

Protection Class
Class I

Components
Push Buttons, Indicator Lamps, Selector Switches, Emergency Stop

Thickness
Different thickness available Millimeter (mm)

Base Material
CRCA Sheet

Control System
PLC/Relay based

Cabinet Material
Sturdy CRCA Steel

Rated Current
250 A

Rated Operation Voltage
415 V

Rated Insulation Voltage
690 V

Panel Type
Control Desk

Product Type
Other

Material
Metal

Surface Finish
Powder Coated

Standard
IEC/ISO Standard

Surface Color
Grey / Blue

Rated Voltage
415 V AC

Frequency (MHz)
50-60 Hertz (HZ)

Maximum Output Current
250 A

Dimension (L*W*H)
1600 x 800 x 2000 mm (approx.)

Application
Jetty Operator Control / Marine Applications

IP Rating
Ip54

Control Panel Desk For Jetty Operator Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash Advance (CA)

Delivery Time
2-8 Week

Main Domestic Market
All India

About Control Panel Desk For Jetty Operator

Control panel desk for jetty operator is a special kind of workstation created just for jetty operators. This kind of desk often has a sizable work surface area in addition to numerous drawers and storage spaces. Additionally, our offering has unique elements like keyboard trays and monitor stands. The operator handles every aspect of running Jetty, including setting up the server, deploying software, and managing log files. Control panel desk for jetty operator has a powder coated surface finish. High grade metal has been used in the formation of this offering. It possesses longer functional life and high-performance efficiency.

Built for Marine Environments

Crafted from sturdy CRCA sheet metal and powder coated for corrosion resistance, this control desk is ideally suited for jetty and marine operator requirements. Its IP54 protection ensures reliable operation against dust and water, making it robust under challenging waterfront conditions. Double earthing and an ergonomic layout provide enhanced safety and ease of use for operators.

Flexible and Safe Configuration

With both top and bottom cable entry provisions and double earthing, the desk supports flexible installation while meeting high safety standards. The internal wiring uses ISI marked wires, and maintenance becomes convenient with both front and rear access. CE marking and strict compliance with IEC/ISO standards guarantee dependable performance and quality assurance.

Comprehensive Operational Features

Designed for operational efficiency, this panel desk integrates essential control elements, including push buttons, indicator lamps, selector switches, and emergency stop features. It supports PLC or relay-based control systems and offers clear visual indicators for seamless decision-making. Optional glass doors, a range of thicknesses, and customizable configurations make it suitable for diverse jetty operator needs.

FAQs of Control Panel Desk For Jetty Operator:

Q: How is the Control Panel Desk for Jetty Operator installed?

A: The desk is designed for floor-mounted installation, providing a stable and secure deployment in jetty or marine environments. It features provisions for cable entry from both the top and bottom, allowing flexible setup according to the sites wiring requirements.

Q: What safety features are included in this control desk?

A: This panel incorporates double earthing provision, ISI marked internal wiring, and a sturdy CRCA steel cabinet. Certified with CE marking and built to IEC/ISO standards, it ensures operator safety, weatherproof performance, and electrical protection with IP54 rating.

Q: Where can the maintenance access be performed on this control desk?

A: Maintenance can be executed efficiently from both the front and rear of the panel, allowing for quick and hassle-free servicing. This dual-access feature minimizes downtime and supports routine inspections or repairs.

Q: What components and control systems are included in the panel?

A: The desk is equipped with a range of operator-friendly controls including push buttons, indicator lamps, selector switches, and an emergency stop. It supports both PLC and relay-based control systems for adaptable marine operation management.

Q: What is the benefit of the glass door option on the control panel desk?

A: The glass door option allows visual inspection of panel components without opening the cabinet, enhancing operator safety and making routine monitoring more convenient. It also adds a modern touch while maintaining secure access.

Q: When is this control panel suitable for use?

A: This control panel desk is ideal for deployment in marine environments such as jetties, docks, and harbor control stations, especially where robust construction, weather resistance, and ergonomic operator interface are essential.

Q: What are the key advantages of using this control panel desk?

A: Key benefits include enhanced safety features, ergonomic and user-friendly design, weatherproof and corrosion-resistant construction, flexible installation, and compliance with global standardsensuring reliability and efficiency in jetty operator duties.
